How To Wire Together solar panels And Solar Battery.
1.Once the battery is connected to the charge controller, it is safe to connect the panels. From the junction box of each panel, you will find two cables - a positive and a negative. In some cases, there may only be two wires that connect directly to the controller. However, typically, there will be MC4 connectors at each end, with a "male" connector for the positive cable and a "female" connector for the negative one.
2.If you have two wires that come out of the junction box, connect them to a complementary pair of connectors that have wires on the other ends. If you have MC4 connectors, simply plug the connectors into the corresponding ports on the charge controller.
3.Once the panels are connected to the controller, it should recognize them. You can verify this by checking the status of your array on the charge controller screen.
4.As soon as the PV modules are exposed to sunlight, they will start generating electricity.
Here's a diagram that shows how to connect the various components of a solar panel system together.
